Adventure just found another gear. Introducing the GVR. Because fast is fun.

In the pursuit of more speed (and more fun) on dirt, gravel, and pavement, we sought every advantage: better aerodynamics, lighter weight, more stiffness, and exceptional comfort. We wanted to give you no excuses—whether on race day or your weekend romp. We wanted hidden cables, ample tire clearance, and precise handling. In short, we wanted it all—and we found it in the GVR

The wild spirit of gravel sends many of us down unknown backroads and trails in the pursuit of adventure. But many of us also seek speed and performance, hunting for the edge of our capabilities. So our product design team created a gravel bike with the traits that performance-hungry riders want and the toughness to handle almost any terrain.

With OBED, you can customize your build more than any other brand. Choose from Shimano or SRAM drivetrains, alloy or carbon wheels, 650b or 700c wheel and tire combos, the exact components you desire, and even a new color-blocked range of frame, fork, and graphic color options. Build your dream gravel bike from the ground up. When you customize a GVR, no two are alike—it’s built just for you.

Learn More about the GVR

This Bike Is For You If...

Finding your wild side includes a lot of race-day action. While the GVR has everything you need for the weekend adventure with friends, the nimble handling, low weight, and aerodynamic design position it neatly for performance-oriented riding. The GVR is engineered for high-speed riding on tough courses. If you like to attack steep and punchy climbs, carve through loose corners, and fly off the front of a fast group, the GVR is for you.

Material

Carbon Fiber

Weight Frame & Fork

1,525g size medium in shadow color

Learn more about the GVR with the Owner's Guide

Read GVR Stories

Frame Details

Frame Specs

Frame Material	Carbon Fiber
Max Tire Size	Through 700x45c or 650x53
Headset Spec	FSA NO.55R
Front Spacing	12x100mm
Front Axle Specs	12x1.5x120-125mm
Rear Spacing	12x142mm
Rear Axle Specs	12x1.5x170-175mm
Seatpost Diameter	31.6mm
Seat Collar Diameter	34.9mm
BB Standard	T47
Max Chainring Size	52/36t
Rotor Max Size (Front)	160mm
Rotor Max Size (Rear)	160mm
Front Derailleur Mount	Braze-on
Derailleur Hanger	Proprietary
Water Bottle Mounts	Yes
Fender Mounts	Add On Option
Rack Mounts	Add On Option
Toptube Bag Mounts	Add On Option
Downtube Accessory Mount	Yes
Fork Offset	50mm
Rigid Fork Length	395mm
Cable Routing	The GVR comes standard with internal cable routing. Contact us regarding an external routing option.

Carbon Fork

Our full-carbon adventure gravel fork is designed with performance, compliance and versatility in mind:

Fork Steer Tube Diameter: 1 1/8” to 1 1/2” tapered
Axle Spacing: 12 x 100mm
Compatible Rotor sizes: 140 and 160mm

Elevate your off-road experience with a fork that combines precision, comfort, adaptability, and style.

Size Chart & Geometry

Size Guide

Bike Geometry

Size	XS	S	M	L	XL
Top Tube Length (mm)	518	527	544	560	581
Head Tube Length (mm)	115	128	146	170	192
Seat Tube Angle	74.5˚	74.5˚	74.0˚	73.5˚	73.0˚
Head Tube Angle	70.5˚	70.5˚	71.5˚	72.0˚	72.0˚
BB Drop (mm)	72	72	71	68	67
Chainstay Length (mm)	425	425	425	425	425
Wheelbase (mm)	1010	1016	1014	1026	1043
Front Center (mm)	596	601	600	611	628
Standover Height (cm)	74.5	76.9	80.7	83.7	86.3
Fork Axle to Crown (mm)	395	395	395	395	395
Fork Rake (mm)	50	50	50	50	50
Seat Tube Length (mm)	460	490	520	550	580
Reach (mm)	370	375	380	385	395
Stack (mm)	534	548	570	590	610

Shipping & FAQs

Shipping & Delivery Options

Obed bikes ship pre-assembled factory direct to your doorstep with a super simple setup process or delivered fully built by a technician. Learn more about our Domestic and International Shipping & Delivery Options.

Have more Shipping Questions? Check out our frequently asked shipping questions.

What should I do if I am between on two sizes?

If you can achieve your required seat height with both bikes sizes, then you can pick based on your riding preference or style. The smaller frame will be more nimble while the larger bike may feel higher and faster. LiveChat with us or email us for help finding the right size.

How do I mount accessories onto my Obed?

Our GVR model has various mounting points for a multitude of accessories available on the market.

For nutrition and hydration, our water bottle and optional top tube storage mounts can be used with most 2-hole accessories designed for M5 x 0.8mm mounts spaced 65mm apart. The screws provided with the frame are 10mm long and should be replaced with longer screws should your accessory mounting bracket be more than 3mm thick.

At the rear of the bike, we offer an optional seat stay brace for mounting. Unlike many metal bikes which may have open ended mounting points, our carbon fiber frames have closed end mounting points. This requires special attention to the length of screw when mounting racks and fenders with various thickness attachments. Should the accessory mounting point be more than 2mm thick, source screws that are 10-13mm longer than the thickness of the item you’re attaching.

We recommend a 20lb load weight limit.

What is your Return Policy?

Put your new bike to the test with our 30 day return policy. If it's not for you, just box it up the way you received it and contact our support team for further instruction.

Reviews

"The GVR is a great gravel bike for myriad riders — anyone from first-timers to pros will find something to love." - Betsy Welch, VeloNews

Read VeloNews Review

"Intended to be an aerodynamic gravel racing machine, it also serves just as useful for getting a road ride fix in as well." - Traece Craig, RBA

Read Road Bike Action's First Ride Review

"Bottom line, the GVR likes to be raced, but it can inspire a rider to do more and go further than just being fast on a fire road."-Road Bike Action

Read Road Bike Action's Gravel Bike Review

"It’s a bike that inspires you to push downhill, even with corners, and it’s a bike that does not ever feel like it was at its limit." - Ryan Heisler, Slowtwitch

Read Slowtwitch's Review
